Feldspar Grinding Mill

Feldspar Raymond Mill – Get 80–400 Mesh Feldspar Powder at Low Cost The most trusted feldspar grinding mill for ceramics, glass, and filler industries. Up to 30% energy savings, minimal iron contamination, and a turnkey solution. Request your custom feldspar powder making machine quote today.

Capacity 2–8 t/h

Power 7.5-220 KW

Input size ≤25 mm

Output size 80–400 mesh

ISO 9001 Certified 20+ Years Global Service

Get Quote WhatsApp

Product Introduction

If you’re tired of high energy bills, inconsistent powder fineness, or iron contamination in your final product, our Feldspar Raymond Mill is engineered to solve exactly these problems. As a specialized feldspar grinding mill machine (feldspar powder making machine) based on the proven Raymond roller mill design, it delivers high-purity, uniform feldspar powder for your exact production needs — batch after batch.

Why a Feldspar Raymond Mill Is Your Best Choice
Unlike ball mills or vertical mills, a raymond mill for feldspar grinding mill offers the ideal balance of capacity, fineness control, and cost-efficiency for small to medium-scale plants. Here’s what makes our feldspar raymond roller mill the industry favorite:

Our Advantages

Ultra-Low Iron Contamination – Pure Feldspar Powder

Our grinding rollers and ring are made of high-chromium alloy, with optional ceramic inserts for zero iron pick-up. This ensures your feldspar powder mill output meets the strict whiteness standards for high-end ceramics, sanitaryware, and ultra-clear glass. Say goodbye to product rejection due to iron spots.

30% Energy Saving – Lower Your Grinding Cost

Optimized grinding cavity and high-efficiency cyclone collector reduce the specific power consumption. Compared to traditional ball mills, our feldspar grinding mill saves up to 30% on electricity. That means a direct boost to your bottom line.

Precise & Uniform Fineness: 80–400 Mesh

Integrated turbo classifier or analyzer ensures a narrow particle size distribution. Whether you need 200 mesh for ceramic body or 400 mesh for filler, this feldspar pulverizer delivers consistent fineness without over-grinding.

Robust & Durable – Minimal Downtime

All wearing parts are cast from wear-resistant materials. The mill uses a centralized lubrication system, extending bearing life. A typical set of grinding rollers can last over 1 year before replacement in standard feldspar processing. This feldspar mill is built for continuous 24/7 operation.

Eco-Friendly & Clean Operation

Fully enclosed negative-pressure system with high-efficiency pulse-jet dust collectors. Dust emission is well below 20 mg/m³, fully compliant with strict environmental regulations. A clean factory with a clean feldspar powder making machine.

Technical Parameter

Model	KL500	KL650	KL780	KL980	KL1100	KL1450	KL1760	KL1950	KL2100
Handling Ability (t/h)	0.5-2	0.5-2.5	1-3	1.5-4	2-6	6-10	8-20	15-30	20-40
Main Motor Power(kw)	7.5	15	18.5	30	45	90	132	185	220
Fan power(kw)	5.5	11	15	22	37	90	132	185	220
Analyst power(kw)	1.1	1.1	2.2	2.2	5.5	7.5	22	37	45
Rotate Speed(r/m)	120	120	120	120	120	90	90	90	90
Diameter of Grinding Ring(mm)	500	650	780	980	1100	1450	1760	1950	2100
Diameter of Grinding Roll(mm)	150	180	260	300	320	400	450	570	630
Maximum Feed(mm)	15	15	15	20	25	30	30	40	40
Finished Particle Size(mm/mesh)	1.6 ------ 0.045mm （16-325 Mesh）					1.6------0.023mm （16-600mesh）
Weight(t)	1.8	2.8	3.8	6.5	14.5	26	48	65	85

Applicable

Ceramic & Tile Manufacturers: As a flux to reduce firing temperature, improve body strength and whiteness.

Glass Factories: Provides alumina for hardness and chemical durability, especially for solar glass and container glass.

Paint & Coating Producers: High-quality feldspar powder used as a functional filler to improve abrasion resistance and weatherability.

Welding Electrode Industry: As an arc stabilizer and slag forming material.

Company Profile

Kolev Equipment Technology Co., Ltd. is a large-scale private technology enterprise. The company is committed to the research and development, production and sales of technical equipment for the mining and metal ore industries. It has been deeply involved in the ultra-fine grinding, industrial drying and crushing sand making industries for many years. We can provide you with Provide intelligent solutions and mature supporting products, focusing on the development of various powder equipment, complete powder production lines, drying production lines, sand and gravel line equipment and projects.Products are sold to 160 countries and regions and are well received by customers.
Kolev Equipment has always been adhering to the business philosophy of surviving by quality and developing by credibility, striving to win the trust of customers with high-quality products and perfect after-sales service, and create a brilliant future for Kolev.

.

Related Cases

Silica Grinding Production Line

The company is a local collection of ore mining, scientific research and development, production and manufacturing, technical services, technical consulting as one of the stone processing enterprises. Due to the need of business development, it is necessary to add a silica grinding production line. After the understanding and field investigation of our company, I was attracted by the professional technology and sophisticated process of Kolev Company, and purchased the complete set of silica grinding production line of our company.

Limestone Grinding Production Line

The company is a local building materials company engaged in the production and sale of limestone powder for a long time. The company adopts scientific management. Due to the development needs of the company, we need to develop high quality limestone products with good purity and fine particle size. After various understanding and field investigation, we are attracted by the professional technology and excellent process of Kolev Company, so we introduce advanced equipment and technology of our company and purchase the full set of limestone grinding production line of our company.

100,000 Tons Fly Ash Deep Processing Project

The company is Kazakhstan a large fly ash processing plant, set fly ash powder research and development, production and sales as one, the products are widely used in cement and concrete and related products. Now, due to the needs of market development, we need to add a high-quality fly ash deep processing production line again. After multiple understanding, comparison and repeated field investigation, we are attracted by the professional technology and sophisticated process of Kolev Company, and purchased the complete set of fly ash deep processing production line equipment of our company.

Lithium ore grinding mill

The client is a benchmark local enterprise in the new lithium-battery materials sector, integrating lithium mining, R&D in mineral processing, manufacturing, and technical services and consulting. Driven by the explosive growth of the new energy vehicle and energy storage industries, downstream lithium carbonate and lithium hydroxide smelters have seen a sharp rise in demand for high-quality spodumene powder (200-mesh). To ensure self-sufficiency, reduce external procurement costs, and strictly control raw material quality, the company decided to add a new, intelligent spodumene-specific grinding production line characterized by ultra-low iron contamination.

Gypsum Calcination Grinding Production Line Site

This company is a large local building materials Co., LTD., which is engaged in gypsum processing, production and sales. Due to the development needs of the company, we now want to add a gypsum processing line. Through the understanding and field investigation of our company, we are attracted by the professional technology and sophisticated technology of Kolev Company, so we purchased a full set of gypsum calcining modified grinding line of our company.

Limestone Grinding Powder Processing Project

The company is a local production, deep processing, sales in one of the lime production enterprises, the company's main calcium hydroxide, ash calcium powder, heavy calcium carbonate, light calcium carbonate, etc., with high-quality raw materials, the use of advanced equipment and production technology, the finished products are widely used in coating, building materials, sewage treatment and other fields. Due to the development needs, we need to add a limestone processing production line. After various communication, project analysis and field investigation, we were moved by the sincerity and professionalism of Kolev Company, and purchased the complete set of limestone grinding production line of our company.

Five tons per hour limestone grinding mill production line

The company is a local building materials company engaged in the production and sale of limestone mill. The company adopts scientific management. Due to the development needs of the company, we need to develop high quality limestone products with good purity and fine particle size. After various understanding and field investigation, we are attracted by the professional technology and excellent process of Kolev Company, so we introduce advanced equipment and technology of our company and purchase the full set of limestone grinding production line of our company.

Dolomite Ultrafine Grinding Project

The company is a local long - term engaged in ore grinding production and sales of building materials company. The company adopts scientific management, due to the development needs of the company, need to develop good purity, particle size fine and other high quality dolomite series products, through various understanding and field investigation, by the company's professional technology and sophisticated technology attracted, special introduction of my company's advanced equipment technology, purchased my company's full set of dolomite grinding production line.
